ErdEditorElement

编辑器就是一个普通的 HTMLElement。
其类型定义如下。

interface ErdEditorElement extends HTMLElement {
  readonly: boolean;
  systemDarkMode: boolean; // system dark/light auto
  enableThemeBuilder: boolean;
  value: string;
  focus: () => void;
  blur: () => void;
  clear: () => void;
  destroy: () => void;
  setInitialValue: (value: string) => void;
  setPresetTheme: (themeOptions: Partial<ThemeOptions>) => void;
  setTheme: (theme: Partial<Theme>) => void;
  setKeyBindingMap: (keyBindingMap: Partial<KeyBindingMap>) => void;
  setSchemaSQL: (value: string) => void;
  getSchemaSQL: (databaseVendor?: DatabaseVendor) => string;
  getSharedStore: (
    config?: SharedStoreConfig & { mouseTracker?: boolean }
  ) => SharedStore;
  setDiffValue: (value: string) => void;
}

readonly

设置编辑器是否可编辑。

editor.readonly = true;
// or
editor.setAttribute('readonly', 'true');

<erd-editor readonly></erd-editor>

systemDarkMode

设置是否自动跟随系统的深色 / 浅色模式。

editor.systemDarkMode = true;
// or
editor.setAttribute('system-dark-mode', 'true');

<erd-editor system-dark-mode></erd-editor>

enableThemeBuilder

设置是否提供便于配置预设主题的 UI。

editor.enableThemeBuilder = true;
// or
editor.setAttribute('enable-theme-builder', 'true');

<erd-editor enable-theme-builder></erd-editor>

更改预设主题时会触发 changePresetTheme 事件。

editor.addEventListener('changePresetTheme', event => {
  const themeOptions = event.detail;
});

value

getter

以 JSON 数据的形式获取当前编辑器状态。

const data = editor.value;

setter

加载此前保存的编辑器状态。会记录到历史列表中，因此可以 Undo, Redo。

editor.value = 'json...';

setInitialValue

加载此前保存的编辑器状态。不会记录到历史列表中，因此无法 Undo, Redo。

editor.setInitialValue('json...');

Event

change

编辑器发生变更时会发出事件。
该事件有 200ms 的防抖，并且在 readonly 为 true 期间不会发出。
为 value 赋值会发出该事件，而 setInitialValue 不会。

editor.addEventListener('change', event => {
  const data = event.target.value;
});

focus

让编辑器获得焦点。

editor.focus();

blur

移除编辑器的焦点。

editor.blur();

clear

重置编辑器状态。

editor.clear();

destroy

彻底销毁编辑器实例，使其无法再被复用。

editor.destroy();

setKeyBindingMap

重新定义键盘快捷键。
edit、stop、search、undo、redo、zoomIn、zoomOut 是固定的，无法重新定义。

type ShortcutOption = {
  shortcut: string;
  preventDefault?: boolean;
  stopPropagation?: boolean;
};

const defaultKeyBindingMap: KeyBindingMap = {
  addTable: [{ shortcut: 'Alt+KeyN', preventDefault: true }],
  addColumn: [{ shortcut: 'Alt+Enter', preventDefault: true }],
  addMemo: [{ shortcut: 'Alt+KeyM', preventDefault: true }],
  removeTable: [
    { shortcut: '$mod+Backspace', preventDefault: true },
    { shortcut: '$mod+Delete', preventDefault: true },
  ],
  removeColumn: [
    { shortcut: 'Alt+Backspace', preventDefault: true },
    { shortcut: 'Alt+Delete', preventDefault: true },
  ],
  primaryKey: [{ shortcut: 'Alt+KeyK', preventDefault: true }],
  selectAllTable: [{ shortcut: '$mod+Alt+KeyA', preventDefault: true }],
  selectAllColumn: [{ shortcut: 'Alt+KeyA', preventDefault: true }],
  relationshipZeroOne: [{ shortcut: '$mod+Alt+Digit1', preventDefault: true }],
  relationshipZeroN: [{ shortcut: '$mod+Alt+Digit2', preventDefault: true }],
  relationshipOneOnly: [{ shortcut: '$mod+Alt+Digit3', preventDefault: true }],
  relationshipOneN: [{ shortcut: '$mod+Alt+Digit4', preventDefault: true }],
  tableProperties: [{ shortcut: 'Alt+Space', preventDefault: true }],
};

// example
editor.setKeyBindingMap({
  addTable: [{ shortcut: '$mod+KeyN', preventDefault: true }],
});

$mod

根据运行环境切换 Control 键。

Mac: $mod = Meta (⌘)
Windows/Linux: $mod = Control

快捷键对照表

使用键盘事件的 key, code 属性。
绝对位置使用 code，输入值使用 key。

Windows	macOS	`key`	`code`
N/A	`Command` / `⌘`	`Meta`	`MetaLeft` / `MetaRight`
`Alt`	`Option` / `⌥`	`Alt`	`AltLeft` / `AltRight`
`Control`	`Control` / `^`	`Control`	`ControlLeft` / `ControlRight`
`Shift`	`Shift`	`Shift`	`ShiftLeft` / `ShiftRight`
`Space`	`Space`	N/A	`Space`
`Enter`	`Return`	`Enter`	`Enter`
`Esc`	`Esc`	`Escape`	`Escape`
`1`, `2`, etc	`1`, `2`, etc	`1`, `2`, etc	`Digit1`, `Digit2`, etc
`a`, `b`, etc	`a`, `b`, etc	`a`, `b`, etc	`KeyA`, `KeyB`, etc
`-`	`-`	`-`	`Minus`
`=`	`=`	`=`	`Equal`
`+`	`+`	`+`	`Equal`

Theme

setPresetTheme

设置预设主题。

type ThemeOptions = {
  appearance: 'dark' | 'light';
  grayColor: 'gray' | 'mauve' | 'slate' | 'sage' | 'olive' | 'sand';
  accentColor:
    | 'gray'
    | 'gold'
    | 'bronze'
    | 'brown'
    | 'yellow'
    | 'amber'
    | 'orange'
    | 'tomato'
    | 'red'
    | 'ruby'
    | 'crimson'
    | 'pink'
    | 'plum'
    | 'purple'
    | 'violet'
    | 'iris'
    | 'indigo'
    | 'blue'
    | 'cyan'
    | 'teal'
    | 'jade'
    | 'green'
    | 'grass'
    | 'lime'
    | 'mint'
    | 'sky';
};

// example
editor.setPresetTheme({ appearance: 'light' });

setTheme

可以自定义主题。

JavaScript

type Theme = {
  grayColor1: string;
  grayColor2: string;
  grayColor3: string;
  grayColor4: string;
  grayColor5: string;
  grayColor6: string;
  grayColor7: string;
  grayColor8: string;
  grayColor9: string;
  grayColor10: string;
  grayColor11: string;
  grayColor12: string;

  accentColor1: string;
  accentColor2: string;
  accentColor3: string;
  accentColor4: string;
  accentColor5: string;
  accentColor6: string;
  accentColor7: string;
  accentColor8: string;
  accentColor9: string;
  accentColor10: string;
  accentColor11: string;
  accentColor12: string;

  canvasBackground: string;
  canvasBoundaryBackground: string;

  tableBackground: string;
  tableSelect: string;
  tableBorder: string;

  memoBackground: string;
  memoSelect: string;
  memoBorder: string;

  columnSelect: string;
  columnHover: string;

  relationshipHover: string;

  toolbarBackground: string;

  contextMenuBackground: string;
  contextMenuSelect: string;
  contextMenuHover: string;
  contextMenuBorder: string;

  minimapBorder: string;
  minimapShadow: string;
  minimapViewportBorder: string;
  minimapViewportBorderHover: string;

  toastBackground: string;
  toastBorder: string;

  dargSelectBackground: string;
  dargSelectBorder: string;

  scrollbarTrack: string;
  scrollbarThumb: string;
  scrollbarThumbHover: string;

  foreground: string;
  active: string;
  placeholder: string;

  focus: string;
  inputActive: string;

  keyPK: string;
  keyFK: string;
  keyPFK: string;

  diffInsertBackground: string;
  diffDeleteBackground: string;
  diffCrossBackground: string;
  diffInsertForeground: string;
  diffDeleteForeground: string;
  diffCrossForeground: string;
};

// example
editor.setTheme({...});

CSS Variables

:root {
  --erd-editor-gray-color-1: #111113;
  --erd-editor-gray-color-2: #18191b;
  --erd-editor-gray-color-3: #212225;
  --erd-editor-gray-color-4: #272a2d;
  --erd-editor-gray-color-5: #2e3135;
  --erd-editor-gray-color-6: #363a3f;
  --erd-editor-gray-color-7: #43484e;
  --erd-editor-gray-color-8: #5a6169;
  --erd-editor-gray-color-9: #696e77;
  --erd-editor-gray-color-10: #777b84;
  --erd-editor-gray-color-11: #b0b4ba;
  --erd-editor-gray-color-12: #edeef0;
  --erd-editor-accent-color-1: #11131f;
  --erd-editor-accent-color-2: #141726;
  --erd-editor-accent-color-3: #182449;
  --erd-editor-accent-color-4: #1d2e62;
  --erd-editor-accent-color-5: #253974;
  --erd-editor-accent-color-6: #304384;
  --erd-editor-accent-color-7: #3a4f97;
  --erd-editor-accent-color-8: #435db1;
  --erd-editor-accent-color-9: #3e63dd;
  --erd-editor-accent-color-10: #5472e4;
  --erd-editor-accent-color-11: #9eb1ff;
  --erd-editor-accent-color-12: #d6e1ff;
  --erd-editor-canvas-background: #212225;
  --erd-editor-canvas-boundary-background: #111113;
  --erd-editor-table-background: #18191b;
  --erd-editor-table-select: #435db1;
  --erd-editor-table-border: #363a3f;
  --erd-editor-memo-background: #18191b;
  --erd-editor-memo-select: #435db1;
  --erd-editor-memo-border: #363a3f;
  --erd-editor-column-select: #2e3135;
  --erd-editor-column-hover: #272a2d;
  --erd-editor-relationship-hover: #435db1;
  --erd-editor-toolbar-background: #111113;
  --erd-editor-context-menu-background: #18191b;
  --erd-editor-context-menu-select: #272a2d;
  --erd-editor-context-menu-hover: #3a4f97;
  --erd-editor-context-menu-border: #363a3f;
  --erd-editor-minimap-border: black;
  --erd-editor-minimap-shadow: black;
  --erd-editor-minimap-viewport-border: #3a4f97;
  --erd-editor-minimap-viewport-border-hover: #435db1;
  --erd-editor-toast-background: #18191b;
  --erd-editor-toast-border: #363a3f;
  --erd-editor-darg-select-background: #253974;
  --erd-editor-darg-select-border: #435db1;
  --erd-editor-scrollbar-track: #ddeaf814;
  --erd-editor-scrollbar-thumb: #696e77;
  --erd-editor-scrollbar-thumb-hover: #777b84;
  --erd-editor-foreground: #b0b4ba;
  --erd-editor-active: #edeef0;
  --erd-editor-placeholder: #e5edfd7b;
  --erd-editor-focus: #435db1;
  --erd-editor-input-active: #5472e4;
  --erd-editor-key-pk: #ffc53d;
  --erd-editor-key-fk: #e54666;
  --erd-editor-key-pfk: #00a2c7;
  --erd-editor-diff-insert-background: #113b29;
  --erd-editor-diff-delete-background: #500f1c;
  --erd-editor-diff-cross-background: #003362;
  --erd-editor-diff-insert-foreground: #3dd68c;
  --erd-editor-diff-delete-foreground: #ff9592;
  --erd-editor-diff-cross-foreground: #70b8ff;
}

setSchemaSQL

加载 Schema SQL 文件。

editor.setSchemaSQL('Schema SQL...');

getSchemaSQL

将当前编辑器状态导出为 Schema SQL。
若未指定 databaseVendor，则按当前已设置的厂商执行。

type DatabaseVendor =
  | 'MariaDB'
  | 'MSSQL'
  | 'MySQL'
  | 'Oracle'
  | 'PostgreSQL'
  | 'SQLite';

const schemaSQL = editor.getSchemaSQL();

getSharedStore

返回用于实时协同编辑的 store。
参见协同编辑。

setDiffValue

比较当前编辑器状态与之前的编辑器状态。

editor.setDiffValue('prev json...');
