ErdEditorElement

The editor is a plain HTMLElement, the <erd-editor> tag that importing @dineug/erd-editor/erd-editor.js defines.
Since 5.0.0 importing the package root defines no tag. The root exports ErdEditorElement as both the element's type and its class, and defineErdEditor(), which defines the tag where you call it — see Registering the Elements.
For a page that only shows a diagram, <erd-viewer> is a read-only element of its own.

import '@dineug/erd-editor/erd-editor.js';

const editor = document.createElement('erd-editor');

Its type definition is as follows.

interface ErdEditorElement extends HTMLElement {
  readonly: boolean;
  systemDarkMode: boolean; // system dark/light auto
  enableThemeBuilder: boolean;
  enableLocalePicker: boolean;
  enableWelcomeScreen: boolean;
  value: string;
  readonly runtimeValue: string;
  focus: () => void;
  blur: () => void;
  clear: () => void;
  destroy: () => void;
  setInitialValue: (value: string) => void;
  setPresetTheme: (themeOptions: Partial<ThemeOptions>) => void;
  setSystemAppearance: (appearance: 'dark' | 'light' | null) => void;
  setTheme: (theme: Partial<Theme>) => void;
  setLocale: (locale: LocaleOption) => void;
  setSystemLocale: (locale: string | null) => void;
  setKeyBindingMap: (
    keyBindingMap: Partial<
      Omit<
        KeyBindingMap,
        | 'edit'
        | 'stop'
        | 'undo'
        | 'redo'
        | 'zoomIn'
        | 'zoomOut'
        | 'zoomReset'
      >
    >
  ) => void;
  setSchemaSQL: SetSchema;
  setSchemaGraphQL: SetSchema;
  setSchemaDBML: SetSchema;
  setSchemaAML: SetSchema;
  setSchemaJSON: (
    value: string,
    options?: { mode?: 'replace' | 'append' }
  ) => void;
  getSchemaSQL: (
    databaseVendor?: DatabaseVendor,
    options?: SchemaSQLOptions
  ) => string;
  getSharedStore: (
    config?: SharedStoreConfig & {
      mouseTracker?: boolean;
      focusTracker?: boolean;
    }
  ) => SharedStore;
  setDiffValue: (value: string) => void;
}

The editor renders into a closed shadow root, so editor.shadowRoot is null and page styles do not leak in or out.
Nothing inside can be reached with a selector — style it through setTheme and the --erd-editor-* custom properties instead.

readonly, system-dark-mode, enable-theme-builder, enable-locale-picker, and enable-welcome-screen are the only attributes, and all five default to false. The last two are new in 4.0.0. Each one reads its value as readonly describes.

Since 4.1.0 the ERD tab has an Explorer, a tree of the diagram docked left of the canvas with Find and Replace at its top. No attribute, property, method, or event opens, closes, or reports it: it opens from the toolbar's Explorer button, from Toggle Explorer in quick search or the canvas context menu, or with the findReplace binding.
Every element starts with it closed. Whether it is open, its width, its folding, and its search last as long as the element does, through tab switches and every load, setInitialValue included, and are never in value, runtimeValue, the undo history, or a shared store.

Since 4.2.0 tables and columns can have logical names beside their names, and the Name View, a document setting like the tab, decides whether the canvas draws their names, their logical names, or both.
The toolbar also has a Dictionary tab, between Code Generator and Settings, holding the document's words, terms, and domains and a Checks sheet. It is a tab like the others: its canvasType, '@dineug/erd-editor/builtin-dictionary', is held by the Canvas Type lock, so a text saved on it opens on it through setInitialValue, and a switch to it is written to value and emits change only while that lock is off. No attribute, property, method, or event of its own opens it or reports on it. Its edits are document changes: they are in value, emit change, and reach collaborators, but their undo and redo run on each sheet's own history, not the document's.
The tab's own place — which sheet shows, Domains at first, and each sheet's search, selection, scroll, and column widths — lasts as long as the element does, through tab switches and every load, and is never in value, runtimeValue, an undo history, or a shared store.
The ErdEditorElement interface gains no member. What the API adds is logicalNameAsComment in getSchemaSQL's options, twelve theme tokens, and the dictionaryRowChords export.

readonly

Sets the editing capability of the editor.
While it is set, assigning value, clear(), setSchemaSQL(), setSchemaGraphQL(), setSchemaDBML(), setSchemaAML(), setSchemaJSON(), undo, and redo, since 4.2.0 a Dictionary sheet's included, are all ignored, and the change event is never emitted. Load a document with setInitialValue instead.
Since 5.0.0 a read-only editor is a reader rather than an editor with its controls disabled. It keeps its six tabs, the Explorer, the minimap, quick search, Table Properties, the Diff Viewer, Export, zen mode, and the cursors, focus, and selections of collaborators, and every control that would edit the diagram is left out instead of drawn disabled. Before 5.0.0 many of its editing controls were still drawn, and the editor dropped what they sent.

On the ERD tab a drag pans wherever it starts, on a table too, and a press selects, moves, and opens nothing. The pointer resting on a table lights its relationships, a still click on a table or a relationship keeps that light, and a still click anywhere else puts it out, as in <erd-viewer>. The only selection is the outline a jump leaves: going to an Explorer row, one of its Find matches, or a quick search result after #, @, or : selects what it reaches, and the next still click clears it. Copying copies what that selection holds.
The canvas toolbar keeps Zoom out, the zoom level (Reset zoom), Zoom in, the Name View list, Zen Mode, and the compass, with no Hand or Select, no New Table, New Memo, or New Table Group, and no relationship buttons. The canvas menu keeps View Option, Name View, Export, and Diff Viewer, the table menu keeps Table Properties, and a memo, a relationship, or a table group raises no menu. Quick search on the ERD tab lists no row that writes the diagram: it keeps Tab, Name View, Database, Export, Toggle Explorer, the Theme and Display Language rows that enableThemeBuilder and enableLocalePicker turn on, and the #, @, and : searches. On the other tabs it lists what it lists in an editable editor. The toolbar shows the database name as text and no Undo, Redo, or Time Travel button.
Nothing offers Import, Import and Add, Auto Layout, a table group row (see Table Groups), or Map Columns, and no welcome screen shows.
The bindings that add, remove, or edit do nothing: edit, addTable, addColumn, addMemo, addTableGroup, groupSelectedTables, removeTable, removeColumn, removeSelection, primaryKey, selectAllTable, selectAllColumn, the four relationship bindings, and handTool, each still prevented as its option says. A paste and Tab do nothing either and reach the page unprevented. The zoom bindings, zenMode, focusView, tableProperties on the table a jump selected, search, findReplace, copying, Escape, and the arrow keys keep working. No cell, memo, or table group name editor opens, and no relationship is drawn.

Find and Replace at the top of the Explorer finds only, with no Toggle Replace arrow and no Replace row. The panel is titled Explorer, and the toolbar button's tooltip is Explorer (Ctrl + F) (Windows/Linux) or Explorer (⌘ + F) (Mac) in every editor. The Explorer has opened in a read-only editor since 4.1.0; from 3.10.0 to 4.0.0 Find and Replace opened there as a find-only floating panel titled Find.
Table Properties opens from the table menu or the tableProperties binding, and since 3.10.0 it shows a Read only badge beside its title and its Indexes tab offers no edits — see Table Properties.
The Settings tab carries the same Read only badge and shows every setting in a control that takes no press: its two switches, the Maximum comment width field, and the seven Lock buttons are disabled, and the Column Order rows do not drag. The Schema SQL tab's Before tables and After tables scripts take no typing. The Visualization tab works as in an editable editor, since nothing there edits the document; Flow's Previous table and Next table still step, by their buttons or the undo and redo keys.
The Dictionary tab still opens: its sheets can be switched, searched, selected, scrolled, and copied from, and a row of the Checks sheet still goes to what it names. No cell takes an edit, a paste, or a clear, the tab shows no Add Row, Delete Rows, Import CSV, or Export CSV tool and no menu on the grid, and its row chords insert and delete nothing. The table menu, the canvas menu, and quick search offer no Derive Physical Names Again or Derive Physical Name Again.

Since 5.0.0 the settings a reader can still change stay on that editor's screen: the scroll and the zoom, the tab, the database, the Code Generator language, both name cases, the bracket type, the View Option rows, and the Name View from each of its pickers, which has stayed on the screen since 4.2.0. Whatever their locks say, none of them reaches value, runtimeValue, the json export, the undo history, the change event, or a shared store, so value keeps the document's settings however the reader looks at it. The Schema SQL and Code Generator option panels caption those settings This window only while readonly is set, where an editable editor's read Saved in the document. What the two tabs show, copy, and save follows the screen, and so does getSchemaSQL called without a vendor.
Before 5.0.0 a reader's scroll, zoom, tab switch, database, and code settings went to value while no lock held them, which the database never has, and a shared store sent them to the other editors.
The Schema SQL tab's own This window only choices, Statements, Header, since 4.2.0 Write logical names into empty comments, and Tables, are never saved in any editor and still apply, and so do the Export image dialog, the theme builder, and the Display Language picker. A pick in the theme builder or the Display Language picker still emits changePresetTheme or changeLocale.

While it is set, nothing enters the undo history, a scroll or a zoom included, and a shared store of the editor sends no change: only what its trackers send of the reader's cursor, focus, selection, and drag box, and the registers another editor asks for when it joins (see Collaborative Editing). It still applies every change the others send. A change of the database, a Code Generator setting, or a View Option row reaches the document, and the screen too unless the reader changed that setting there, and a shared Name View switch shows on the screen either way. Since 5.1.0 a Code Generator language, name case, or bracket type changed while that setting's lock is on stays on the screen of the editor that changed it and is never sent, so it reaches neither the reader's document nor its screen. A change made with the lock off, and the value an unlock carries, still reach it as above.

Turning it on ends what stood open: a cell, memo, or table group name editor, a relationship being drawn, a drag of a table, memo, table group, or column, an Alt drag's copies, a memo or table group resize, an Auto Layout preview or placement still running, Map Columns, Time Travel, and the color picker. It clears the selection, puts the hand tool down, and first sends what each shared store still holds back of a drag or a scroll, as flushStreamBuffers does. Table Properties, now read-only, the Diff Viewer, and the Export image dialog stay open, and the scroll, zoom, tab, and Name View stay as they were. An element that is read-only when it first mounts starts the same way, and one a host moves in the page keeps the outline a jump left.
Turning it off brings the editing controls back with nothing selected or open. Each of the database, the Code Generator language, both name cases, the bracket type, and the View Option rows that the reader changed goes back to what the screen showed before the reader first changed it: the document's value, with any change the others sent meanwhile, or a value this editor showed of its own under the setting's lock, which value never held. The scroll, zoom, tab, and Name View stay where the reader left them, and value keeps the document's settings until they are changed again. Neither turn emits change.
A bare attribute, ="", and ="true" all read as true. ="false" reads as false, and so does any other string — including the HTML idiom readonly="readonly".

editor.readonly = true;
// or
editor.setAttribute('readonly', 'true');

<erd-editor readonly></erd-editor>

systemDarkMode

Determines whether to automatically synchronize with the system's dark/light mode.
Since 4.0.0 turning it on sets the theme's appearance to 'system', as setPresetTheme({ appearance: 'system' }) does. The editor then shows the light or dark the operating system reports, or the one setSystemAppearance names, and switches when that changes.
A later setPresetTheme with 'light' or 'dark', or a Light or Dark pick in the theme builder or quick search, replaces 'system' and stays: the next OS change no longer overwrites it, even though systemDarkMode is still true. Before 4.0.0 the next OS change overwrote it.
Turning it off while the appearance is 'system' keeps the light or dark shown at that moment. Turning it off after the appearance has been changed away from 'system' leaves it as it is.
Changing it emits no event.

editor.systemDarkMode = true;
// or
editor.setAttribute('system-dark-mode', 'true');

<erd-editor system-dark-mode></erd-editor>

enableThemeBuilder

Determines if a UI for easily setting preset themes is provided.
It shows the toolbar's Theme button, which opens the theme builder with Accent color, Gray color, and Appearance. Since 4.0.0 Appearance offers System beside Light and Dark, and while this is on, quick search lists Theme with System, Light, and Dark. See Language and Theme.

editor.enableThemeBuilder = true;
// or
editor.setAttribute('enable-theme-builder', 'true');

<erd-editor enable-theme-builder></erd-editor>

Changing the preset theme from this panel, or from quick search, emits the changePresetTheme event.

enableLocalePicker

Since 4.0.0, determines if a UI for picking the editor's display language is provided.
It shows the toolbar's Display Language button, after Theme when both are shown. The button opens the Display Language picker, and quick search lists Display Language. Both offer System and the 25 languages — see Language and Theme.
It also decides what an editor shows before setLocale is called or a language is picked: 'system' while it is on, English while it is off, so an element that configures nothing keeps the English it always showed. Turning it on or off switches between the two at once. Once a language has been set or picked, that choice stays whichever way it is turned.
Set it before the element is appended for the first frame to follow 'system'.
A pick emits changeLocale.

editor.enableLocalePicker = true;
// or
editor.setAttribute('enable-locale-picker', 'true');

<erd-editor enable-locale-picker></erd-editor>

enableWelcomeScreen

Since 4.0.0, determines if an empty diagram greets the reader with the welcome screen.
It stands over the ERD tab while the document has no table, no shown memo, and no shown table group. It is not shown while readonly is set, in zen mode, or while Table Properties, the diff viewer, time travel, or the Auto Layout preview is open. The first table, shown memo, or shown table group takes it away, and an undo back to an empty diagram brings it back.
Its New Table, New Memo, and Command Palette rows show the first chord of addTable, addMemo, and search as setKeyBindingMap left them, and none for a name left empty. Its arrows point at the Theme and Display Language buttons only where enableThemeBuilder and enableLocalePicker show them.
In its menu, ↑, ↓, Home, and End move between the rows and are prevented and stopped. Enter and Space are stopped, not prevented, so the focused row takes them, and Escape among the Import formats goes back, prevented and stopped. Every other key reaches the editor and the page as usual.
It changes nothing in the document, so it leaves value as it was and emits no change.
Turn it on once setInitialValue has loaded the document, as the official hosts do, so the screen never flashes over a file that is still loading.

editor.enableWelcomeScreen = true;
// or
editor.setAttribute('enable-welcome-screen', 'true');

<erd-editor enable-welcome-screen></erd-editor>

value

getter

Retrieves the current document as a JSON string, in the schema the editor defines.
Since 4.0.0 it is the storage form, the document as a file holds it, which is also what the json export writes and the official hosts save. It holds the live entities alone, without the removed ones, the stacking order, or what the editor works out for itself, such as measured widths, key marks, and relationship anchors. Its entities are keyed in a fixed order, it is indented two spaces, and it ends with a newline, so the same document always gives the same bytes.
Since 4.2.0 it also leaves out what is empty: an empty doc list, an empty collection, a dictionary row that holds nothing, and an entity's empty text field, such as a name, comment, data type, default, or color. A list inside an entity, such as a table's columnIds, is still written when empty. A new document's doc is {}, and it has no collections, so read a missing field, list, or collection as empty. It holds the logical names and derived-name flags of tables and columns, the columns' domain links, and the words, terms, and domains, each dictionary written as one header of field names followed by its rows, one row to a line, in the sheet's order. See Storage Form.
Each setting whose lock is on is written at the value it is locked at, not as the screen shows it. The Viewport lock holds originX, originY, and zoomLevel, and Canvas Type, Language, Table Name Case, Column Name Case, Bracket Type, and since 4.2.0 Name View each hold their own setting. The Name View is written as nameViewMode, and only while it is not 'physical'. Every other setting is written as it stands, and lockSettings is always written. See Settings for the bits; the Name View lock's bit reads the other way round.
Since 5.0.0 the settings a read-only editor's reader changes are written at the document's values too, locked or not, since they stay on that screen.
A new document has every lock on, whether it is the one an element shows before it is given a value or one loaded from a blank value. Its value keeps the origin at 0, 0, the zoom level at 1, the ERD tab, the default Code Generator language, name cases, and bracket type, and since 4.2.0 Physical Names, until the matching lock is turned off.
Before 4.0.0 it returned the whole document as the editor held it, with ignoreSaveSettings applied. The document as the editor holds it is now runtimeValue, and ignoreSaveSettings is no longer read or written.

const data = editor.value;

setter

Loads a previously saved editor state. It replaces the whole document — the current one is cleared first. Since 4.2.0 that includes the words, terms, and domains: the document takes the ones the text holds, or none, and every Dictionary sheet's own undo history is emptied.
Like clear(), setInitialValue(), and the setSchema* methods in their default mode: 'replace', it also discards the Visualization tab's Flow view: its layout, the tables it is narrowed to, its row display, zoom, and pan, and since 4.2.0 the tables its Previous table and Next table step through. An append (mode: 'append') does not discard it.
Since 5.1.0 it ends a relationship being drawn, whether only its type is armed or its parent table is already picked. So do clear(), the setSchema* methods in mode: 'replace', the editor's own Import, an undo or redo of any of these except an undo of clear(), and each of them received through a shared store, from a collaborator or a coding agent. Before 5.1.0 the draw stayed armed through the load, and where the loaded text, such as the runtime value an undo carries, held the table it started from as a removed entity, a press could then add a relationship from that removed table. An append leaves a draw armed.
As before, a memo, table group name, or cell editor stays open while the loaded document still holds, and shows, what it edits, and closes otherwise; typing in one left open goes on into the loaded document. Since 5.1.0 an editor that any load closes leaves the keyboard to the page rather than handing it back to the editor, so a Delete or Backspace meant for the closed text removes nothing of the selection. A logical name cell left open through such a load derives the physical name as it closes only from a logical name the user typed, never, since 5.1.0, from one the load brought.
It is recorded in the history list, enabling Undo, Redo, and it emits change.
It takes the storage form, a runtimeValue, or a file an earlier release saved.
A blank string, or anything that is not a string, loads a new document rather than raising an error, so guard the value before assigning it.
That new document is the one setInitialValue('') starts: empty, with default settings, and since 4.0.0 with every lock on. In 3.10.x it saved neither the scroll position nor the zoom level, and before that it saved both.
A shared store relays that load to collaborators with the new document's full JSON, so every peer, an older release included, loads it, though an editor before 4.2.0 drops what it does not know, such as the logical names, domain links, and dictionaries — see Mixing Releases.
Since 4.0.0 the loaded document's locks, and the locked values value then writes, come from the text, and the view lands where the text puts it, or on the diagram when none of it is drawn there. For each other setting the text locks — the tab, the Code Generator language, the name cases, the bracket type, and since 4.2.0 the Name View — the editor keeps showing what it showed before the load. A setting the text leaves unlocked takes the text's value. A file saved before 4.2.0 names no Name View lock unless a 4.2.0 editor turned that lock off in it, so it loads with the Name View locked at Physical Names, and the editor keeps the Name View it showed. setInitialValue instead takes every value the text holds; see it also for a text that names no locks.
Text that is not JSON, such as a file left with merge-conflict markers, does not raise an error either: the document is emptied, its settings stay as they were, and the parse error is logged to the console.
It is ignored while readonly is set; use setInitialValue to load into a read-only editor.

editor.value = 'json...';

runtimeValue

Since 4.0.0, retrieves the document as this editor holds it, as a JSON string. It has no setter, so assigning it throws in strict-mode code.
It carries what value leaves out: removed entities and their order, stacking order, measured widths, key marks, each relationship's flags (whether it is identifying, and how its parent end is drawn) and anchors, and sequences.
Since 4.2.0 it also keeps the empty things value leaves out: an entity's empty text, such as a name, comment, data type, default, color, or memo text; the doc lists tableIds, relationshipIds, indexIds, and memoIds and the collections tableEntities through memoEntities, written even while empty; the table group list and collection while the document holds a group or a removed one; and each dictionary with its doc list while either holds an entry. It keeps a logical name of only blanks, a link to a removed domain, the rows removed from a Dictionary sheet, and those that hold nothing. As in value, a logical name, a domain link, or a table's group that is '', and a table's derived-name flag that is off, are left out.
Each dictionary is a header and rows, as in a file, but its header names "order", each row's order key, right after "name", and its rows stand in the order the editor holds them, removed rows included, rather than the sheet's. For the sheet's order, take the rows its doc list names and sort them by order, compared in code-unit order, and rows that share a key by id.
Its settings are written as value writes them, each locked setting at its locked value. It is indented two spaces, each dictionary row on a line of its own, and unlike value it ends with no newline.
Use it to seed another editor that joins a session already running, such as a collaborator or a second view of the same document, through its setInitialValue. An undo of a removal that the session sends later then restores the entity whole there, while an editor seeded from value holds no removed entity and restores an empty, nameless table, or since 4.2.0 an empty dictionary row, instead. See Collaborative Editing.
Nothing collects removed entities any more, so they stay in it until the document is next opened from its file.
Never write it to a file: save value, which the JSON Schema accepts and this does not.

otherEditor.setInitialValue(editor.runtimeValue);

setInitialValue

Loads a previously saved editor state. The load itself is not recorded in the history list, so it cannot be undone, and no change event is emitted.
It also clears the undo history, so nothing done before the load can be undone or redone onto the loaded document, and since 4.2.0 each Dictionary sheet's own history too.
It takes the storage form, a runtimeValue, or a file an earlier release saved, and unlike assigning value it takes every setting the text holds, the tab and the code settings included.
A blank string, or anything that is not a string, loads a new document rather than raising an error, so setInitialValue('') starts a blank diagram.
Since 4.0.0 that new document, which is also what an element shows before it is given any value, has every lock on. Scrolling, zooming, switching tabs, and changing the Code Generator language, the name cases, the bracket type, or since 4.2.0 the Name View leave value as it was and emit no change. In 3.10.x it saved neither the scroll position nor the zoom level, and before that it saved both.
A document loaded from text keeps the locks it names. One that names none — any file saved before 4.0.0, whatever its ignoreSaveSettings said, and a v2 .vuerd file — opens with every lock on, its Viewport locked at origin 0, 0 and zoom level 1, on the ERD tab, with its language, name cases, and bracket type as it saved them.
Since 4.2.0 a text that names its locks but not the Name View lock opens with that lock on too, even when every other lock is off. A file saved before 4.2.0 is such a text unless a 4.2.0 editor turned that lock off in it (see Settings). It opens in Physical Names, as one that names no lock at all does.
Either way the view opens at the document's view — the one the text saved when it names its locks, origin 0, 0 at zoom level 1 when it names none — or on the diagram when none of it is drawn there. A locked Viewport still keeps its locked values in value.
Since 4.0.0 it also drops the collaboration state of the document held before, and a shared store of this editor that is already subscribed asks the other editors for theirs again, so an editor reloaded in a running session catches up. Seed such an editor with another editor's runtimeValue.
Since 5.1.0 the collaboration registers can come with the seed instead, which a stored snapshot needs when no running editor is there to answer.
After this call, never before it, pass another store's getLWW() and getVersion() to mergeLWW on this editor's shared store. Or load through that store's reseed, which loads and takes them in one call and also drops the selection and the focus. See Seeding a Collaborator.
Text that is not JSON does not raise an error either: the document is emptied, its settings stay as they were, and the parse error is logged to the console.
Unlike assigning value, it is not blocked by readonly, so it is how you load a document into a read-only editor. A read-only editor then shows the settings the loaded text holds, dropping the ones its reader had changed on screen.

Since 5.1.0 it ends a relationship being drawn and closes an open memo, table group name, or cell editor, even where the loaded document still holds what that editor edits. Before 5.1.0 the draw stayed armed, and each editor stayed open while the loaded document still held its memo, group, or table and column.
Closing them writes and sends nothing: a memo's text and a cell's value were already written as they were typed, into the document held before, while a Domain cell's search, which writes nothing until a domain is picked, and a table group name typed and not yet entered are dropped.
The one exception is a logical name cell the user typed in: where the loaded document holds the logical name last typed there, the close derives the physical name from it, as any close of that cell does. That derive is an edit like any other, so a shared store sends it, it makes an undo entry, and it emits change.
The selection and the focused cell stay, and the keyboard is left to the page, as the setter describes for any load. A shared store's reseed closes the same.

editor.setInitialValue('json...');

Load on start, save on change.

editor.setInitialValue(localStorage.getItem('my-diagram') ?? '');
editor.addEventListener('change', () => {
  localStorage.setItem('my-diagram', editor.value);
});

Event

change, changePresetTheme, and changeLocale are the only three public events; changeLocale is new in 4.0.0.
The element also dispatches internal @dineug/erd-editor/internal-* events on itself for its own wiring; those are not part of the API.

change

When there are changes in the editor, it emits an event.
The event is debounced by 200ms, and it is not emitted while readonly is true.
It fires for any document change — an edit in the UI, assigning value, clear(), each of the setSchema* methods, and since 4.0.0 setSchemaJSON() and Import and Add. setInitialValue does not emit it, and since 5.1.0 neither does a shared store's reseed, except for the physical name either derives as it closes a logical name cell the user typed in (see setInitialValue).
Since 4.2.0 that includes every edit on the Dictionary tab and every undo or redo of one, a change of a logical name or a domain link, Derive Physical Names Again, and a Name View switch while the Name View lock is off.
Nothing done inside the Visualization tab's Flow mode emits it — zoom, panning, moving cards, Tidy Up, the row display, narrowing the view from a card, or since 4.2.0 stepping with Previous table and Next table or the undo and redo keys — since none of it is a document change. Its Name View list is the exception: a switch there emits it while the Name View lock is off, as one on the ERD tab does.
Since 4.0.0 a change to a setting whose lock is on does not emit it either, because it moves only the screen and never value: a scroll or a zoom of the ERD canvas while Viewport is locked, a tab switch while Canvas Type is locked, a change of the Code Generator language, the table name case, the column name case, or the bracket type while its own lock is on, and since 4.2.0 a Name View switch while Name View is locked. Only those changes are left out, so a batch that also edits the document still emits it. Locking or unlocking a setting emits it.
Every lock is on in a new document and in any file saved before 4.0.0, and the Name View lock is on in any file saved before 4.2.0 unless a 4.2.0 editor turned it off there, so by default scrolling, zooming, switching tabs, and switching the Name View emit nothing. That covers focusing on tables from the ERD tab, the external-link card button that takes you from Flow back to the ERD tab, going to an Explorer row or a search match, opening the Explorer or going to a quick search result from another tab, and since 4.2.0 going to a table or column from a row of the Dictionary tab's Checks sheet. Each of those emits one change only while a lock that covers it is off: Canvas Type for the tab switch, and Viewport for the scroll a card button, a quick search result, an Explorer row, a search match, or a Checks row also makes. Since 4.1.0 every one of those scrolls follows one rule, Where a Jump Lands, so a quick search table result no longer scrolls every time, and a jump the rule leaves in place makes no scroll to emit. Opening, closing, or resizing the Explorer narrows or widens the canvas without moving its origin, and emits nothing either. Before 4.0.0 scrolling, zooming, and switching tabs always emitted it, even when editor.value came out the same.
To skip writes that change nothing, compare editor.value with the value you last stored, not with the file you loaded: a file an earlier release wrote, a v2 file, or a hand-edited one can come out different in value as soon as it loads, because value writes it in the storage form. So can a file whose Viewport lock is off and whose origin draws none of the diagram on this screen: the load moves the view onto the diagram, and value writes where it lands. Since 4.0.0 measured widths no longer cause this, because value holds none. Since 4.2.0 a file 4.0.0 or 4.1.0 saved can come out different too, as value now leaves out its empty text fields, lists, and collections, so such a file is rewritten once, on its next save. A host that writes files can instead tell an edit from a view change with a replication store's changed — see on@change.
The event carries no detail and neither bubbles nor crosses the shadow boundary, so listen on the element itself and read editor.value in the handler.

editor.addEventListener('change', event => {
  const data = event.target.value;
});

changePresetTheme

Emitted when the preset theme is changed from the built-in theme builder, or since 4.0.0 from Theme in quick search. Every pick emits it, a pick of the option already in force included.
Calling setPresetTheme or setSystemAppearance yourself, or turning systemDarkMode on or off, does not emit it.
event.detail is the complete ThemeOptions after the pick — { appearance, grayColor, accentColor } — not the partial that was requested. Since 4.0.0 its appearance is 'system' while System is picked, not the light or dark it shows, so store it as it is and hand it back to setPresetTheme.

editor.addEventListener('changePresetTheme', event => {
  const themeOptions = event.detail;
});

changeLocale

Since 4.0.0, emitted when a language is picked in the editor, from the Display Language picker or from Display Language in quick search, both of which enableLocalePicker turns on.
It fires after the language has been applied, on every pick, a pick of the option already in force included. setLocale and setSystemLocale never emit it, and neither does a change of the browser's languages. A switch of language emits no change.
event.detail is { locale }, a LocaleOption: 'system' when System was picked, otherwise the language's code. The element does not remember the pick, so store it and pass it to setLocale on the next load.
Like change, it does not bubble, so listen on the element itself.

editor.addEventListener('changeLocale', event => {
  const { locale } = event.detail; // 'system' | 'ko-KR' | ...
});

focus

Focuses on the editor.

editor.focus();

blur

Removes focus from the editor.

editor.blur();

clear

Empties the document, removing every table, column, relationship, index, and memo, since 4.0.0 every table group, and since 4.2.0 the Dictionary tab's words, terms, and domains, emptying every sheet's own undo history too.
Every setting stays, including the database, the view position, the zoom level, the table view options, each lock with the value it holds, and the Schema SQL tab's Before tables and After tables scripts, so a cleared file keeps saving what it saved. To start a new document instead, assign '' to value or call setInitialValue('').
It is recorded in the history list, so it can be undone, and it emits change. An undo brings the document back as the editor held it, its words, terms, and domains included, each locked setting at its locked value. It is ignored while readonly is set.
Since 5.1.0 it ends a relationship being drawn, as the value setter describes, and so does its redo; its undo does not.
As before, a memo, table group name, or cell editor left open closes, since the emptied document holds nothing to edit. Since 5.1.0 the closed editor leaves the keyboard to the page, as after a load.

editor.clear();

destroy

Completely destroys the editor instance so that it can no longer be reused.
It releases the editor's listeners and subscriptions, and destroys every shared store returned by getSharedStore.
A stream batch a shared store is still holding back is dropped with it; call that store's flushStreamBuffers first to send it.

editor.destroy();

setKeyBindingMap

Redefines keyboard shortcuts.
edit, stop, undo, redo, zoomIn, zoomOut and zoomReset are fixed and cannot be redefined.
Only the twenty-one names below are written; anything else in the object is ignored, including the fixed names.
Since 3.10.0, search can be redefined, and findReplace is new. Before, search was fixed. Since 4.0.0, removeSelection is new. Since 4.1.0, addTableGroup and groupSelectedTables are new.
A binding value must be a ShortcutOption[]. A bare string is ignored, so write { addTable: [{ shortcut: 'Alt+KeyN' }] } rather than { addTable: 'Alt+KeyN' }.
An empty array is accepted and binds nothing: setKeyBindingMap({ findReplace: [] }) leaves Ctrl + F (Windows/Linux) or ⌘ + F (Mac) to the page, and { search: [] } does the same for Ctrl + K (Windows/Linux) or ⌘ + K (Mac). The toolbar's Search button still opens quick search, the toolbar's Explorer button still opens and closes the Explorer, and Toggle Explorer in quick search and in the canvas context menu still opens its search or closes it; none of these shows a shortcut for a name left empty. { removeSelection: [] } leaves Delete and Backspace to the page, and the delete rows of the table, memo, and table group menus (Delete, Delete selected, Delete column, Delete columns) then show no shortcut.
Since 4.1.0, { addTableGroup: [] } leaves Alt + G (Windows/Linux) or ⌥ + G (Mac) to the page, and { groupSelectedTables: [] } leaves T then G. New Table Group on the canvas toolbar, in the canvas context menu, and in quick search, Group selected tables in the table menu, and Group Selected Tables in quick search still work, with no shortcut shown. The tooltips of the canvas toolbar's New Table, New Memo, and New Table Group buttons name the first chord of addTable, addMemo, and addTableGroup, or only the button for a binding left empty.
Since 4.2.0, addColumn and removeColumn also give the Dictionary tab's grid its row chords, as below, so rebinding either moves those chords with it. { addColumn: [] } leaves the grid no chord to insert rows, and the grid menu's two insert rows then show no shortcut; { removeColumn: [] } leaves it none to delete them, and the menu's delete row and the Delete Rows tooltip then show none.
The call is a partial merge: names you leave out keep their defaults, and calling it twice keeps the earlier changes. There is no getter for the current bindings: createKeyBindingMap returns the defaults, not what setKeyBindingMap changed.

type ShortcutOption = {
  shortcut: string;
  preventDefault?: boolean;
  stopPropagation?: boolean;
};

const defaultKeyBindingMap: Omit<
  KeyBindingMap,
  | 'edit'
  | 'stop'
  | 'undo'
  | 'redo'
  | 'zoomIn'
  | 'zoomOut'
  | 'zoomReset'
> = {
  search: [
    { shortcut: '$mod+KeyK', preventDefault: true, stopPropagation: true },
  ],
  findReplace: [
    { shortcut: '$mod+KeyF', preventDefault: true, stopPropagation: true },
  ],
  addTable: [{ shortcut: 'Alt+KeyN', preventDefault: true }],
  addColumn: [{ shortcut: 'Alt+Enter', preventDefault: true }],
  addMemo: [{ shortcut: 'Alt+KeyM', preventDefault: true }],
  addTableGroup: [
    { shortcut: 'Alt+KeyG', preventDefault: true, stopPropagation: true },
  ],
  groupSelectedTables: [{ shortcut: 'KeyT KeyG', preventDefault: true }],
  removeTable: [
    { shortcut: '$mod+Backspace', preventDefault: true },
    { shortcut: '$mod+Delete', preventDefault: true },
  ],
  removeColumn: [
    { shortcut: 'Alt+Backspace', preventDefault: true },
    { shortcut: 'Alt+Delete', preventDefault: true },
  ],
  removeSelection: [
    { shortcut: 'Delete', preventDefault: true },
    { shortcut: 'Backspace', preventDefault: true },
  ],
  primaryKey: [{ shortcut: 'Alt+KeyK', preventDefault: true }],
  selectAllTable: [
    { shortcut: '$mod+KeyA', preventDefault: true },
    { shortcut: '$mod+Alt+KeyA', preventDefault: true },
  ],
  selectAllColumn: [{ shortcut: 'Alt+KeyA', preventDefault: true }],
  relationshipZeroOne: [{ shortcut: '$mod+Alt+Digit1', preventDefault: true }],
  relationshipZeroN: [{ shortcut: '$mod+Alt+Digit2', preventDefault: true }],
  relationshipOneOnly: [{ shortcut: '$mod+Alt+Digit3', preventDefault: true }],
  relationshipOneN: [{ shortcut: '$mod+Alt+Digit4', preventDefault: true }],
  tableProperties: [{ shortcut: 'Alt+Space', preventDefault: true }],
  focusView: [
    { shortcut: 'Alt+KeyF', preventDefault: true, stopPropagation: true },
  ],
  handTool: [{ shortcut: 'Space', preventDefault: true }],
  zenMode: [
    { shortcut: 'Alt+KeyZ', preventDefault: true, stopPropagation: true },
  ],
};

// example
editor.setKeyBindingMap({
  addTable: [{ shortcut: '$mod+KeyN', preventDefault: true }],
});

selectAllTable, handTool, removeSelection, and since 4.1.0 groupSelectedTables give way to a caret: while the focus is in an input, a textarea, or a contenteditable, $mod + A selects the text, Space types a space, Delete and Backspace erase text, and T then G types the two letters, instead of reaching the canvas. None of those presses is prevented. Whatever you rebind them to behaves the same way.

Since 4.0.0, removeSelection (Delete or Backspace) removes the selection on the ERD tab as one undo step, without asking. When the focused table is the only thing selected, one or more of its columns are selected, and the zoom draws its rows, it removes those columns; otherwise it removes every selected table, memo, and table group, a group's tables kept. See Table and Memo Deletion.
A held key removes once, and nothing is removed while a cell, memo, or table group name editor is open. Outside a text field and the panels and tabs that hold bindings back (see createKeyBindingMap), the press is prevented on every tab while the editor has focus, on a focused toolbar button too, and in a read-only editor, where it removes nothing.

Since 4.1.0, addTableGroup (Alt+KeyG) arms the New Table Group draw on the ERD tab, whose next main-button press on the canvas draws the group, and pressing it again disarms the draw, as the canvas toolbar's New Table Group button does. groupSelectedTables (KeyT KeyG, T then G) puts the selected tables in a new group and opens its name editor, as Group selected tables in a table's context menu does. With no table selected it adds nothing; a selected memo or table group does not count. See Drawing a Group and Grouping Selected Tables.
Both act only where the menus offer a group: not while readonly is set, while the Table Groups view option hides the groups, or while a cell, memo, or table group name editor is open. Like the other canvas bindings, they act only on the ERD tab, and not while quick search, Table Properties, the diff viewer, time travel, the Auto Layout preview, Export image, or Map Columns is open. Where they do nothing, the press is still prevented, unless groupSelectedTables gives way to a caret. addTableGroup is also stopped, as focusView and zenMode are, so a page's bubbling keydown listener never hears it.

Since 4.2.0, on the Dictionary tab, each one-press chord of addColumn inserts as many rows below the selection as the selection covers, the same chord with Shift held as well inserts them above, and each one-press chord of removeColumn deletes the rows the selection covers: Alt+Enter, Alt+Shift+Enter, and Alt+Backspace or Alt+Delete with the defaults. They act in the grid of the Domains, Words, and Terms sheets while no cell edit is open. A chord of addColumn that already holds Shift gives no chord to insert above, and a sequence bound to either name gives the grid nothing.
Each such press is prevented as its option says and always stopped, so it adds or removes no column on the ERD tab. On the Checks sheet and in a read-only editor it does nothing, though it is still prevented and stopped. In an open cell edit or the tab's search field the chords are left to the text: they are stopped there but not prevented, so the field acts on them as it would anywhere (on a Mac, ⌥ + Backspace deletes a word). dictionaryRowChords lists them.

Since 3.10.0, findReplace ($mod+KeyF) opens Find and Replace. Since 4.1.0 it toggles the Explorer that holds it, and the Shortcuts tab lists it as Toggle Explorer.
While the toolbar's Explorer button shows pressed (the Explorer open on the ERD tab and not hidden by zen mode), it closes the Explorer, unless quick search, Table Properties, the theme builder, the Display Language picker, the Export image dialog, or Map Columns is open. Otherwise it closes whichever of those is open, brings the ERD tab up from any other tab, and opens the Explorer with the caret in its Find field and the query selected. An editor too narrow to show the Explorer beside the canvas keeps it open but aside, and shows the toast Widen the window to show the Explorer. Before 4.1.0 it opened the floating Find and Replace panel, or gave its field the keyboard back, and never closed it.
It does not give way to a caret: while the editor is focused it is taken on every tab, from the canvas or from an input inside the editor. The press is prevented, so the browser opens no find bar, and stopped, so no bubbling keydown listener on the page hears it. With a cell or memo editor open, since 4.0.0 a table group name editor, or since 4.2.0 a cell edit in the Dictionary tab's grid, it is still prevented and stopped, but does nothing. In that last case search does nothing either, so the text typed so far stays.
While the diff viewer, time travel, or the Auto Layout preview is open, on whichever tab, or while an IME is still composing, it is neither prevented nor stopped, so the browser's or the host's own find gets it. Inside the Explorer, a press still composing is stopped there, though not prevented. Whatever you rebind findReplace to behaves the same way.

focusView acts on the ERD tab only. With at least one table selected, it opens the Visualization tab in Flow mode, narrowed to those tables and every table one relationship away; a selected memo or table group does not count, and with no table selected it does nothing. See Focusing on Tables.

undo and redo act by tab. On the ERD tab they undo and redo the document's history. Since 4.2.0 on the Dictionary tab they undo and redo the shown sheet's own history, and nothing on the Checks sheet — see Dictionary Sheets. In the Visualization tab's Flow mode they step back and forward as Previous table and Next table do, leaving the document's history alone. On the other tabs, and in Graph mode, they undo nothing.

stop (Escape) on the ERD tab ends an open cell or memo editor, or a relationship being drawn, and leaves the selection as it is. Since 4.0.0 it also ends a table group name editor, writing no name, and a New Table Group draw. The editor calls preventDefault() on that press.
With none of those open, Escape clears the selection and the focused cell, and is not prevented. Leaving an edit and clearing the selection therefore takes two presses.
Since 4.2.0, while a logical name cell's term list shows (see Completing Term Names), the first Escape closes the list alone and leaves the editor open. That press is prevented and stopped at the cell, so neither stop nor a page's bubbling keydown listener hears it.
Apart from the Explorer, the welcome screen's Import formats, a logical name cell's term list, the Dictionary tab, and the pickers and dialogs below, the editor never stops Escape from propagating, so a page that listens for it itself, to close a dialog of its own for example, hears both presses and can skip the one whose defaultPrevented is true.
While quick search, table properties, the diff viewer, the Auto Layout preview, or time travel is open, Escape closes that instead and leaves the selection as it is. That press is not prevented either.
Since 4.0.0 an open Export image or Map Columns dialog also takes Escape, closing itself and leaving the selection as it is. Each takes the keyboard when it opens, and that Escape is both prevented and stopped.
Since 4.1.0 an Escape pressed with the focus inside the Explorer, in its tree, its fields, or its buttons, gives the keyboard back to the canvas and leaves the Explorer open and the selection as it is. The editor calls both preventDefault() and stopPropagation() on it, so it never reaches a page's bubbling keydown listener.
An Escape on the canvas never closes the Explorer. Before 4.1.0 an Escape inside the Find and Replace panel closed it, and one on the canvas closed it in the same press that cleared the selection.
Since 4.0.0 the Display Language picker and the color picker close on Escape: inside them it is prevented and stopped, and on the canvas it closes them in the same press that clears the selection, neither prevented nor stopped.
An Escape pressed while an IME is still composing belongs to the composition. It leaves an open editor as it is and is not prevented, so a page can skip a press whose isComposing is true, or whose keyCode is 229, as well. Inside the Explorer such a press, like any key pressed there mid-composition, is also stopped, and the keyboard stays in the field.
Before 3.9.2 a single Escape both ended an edit or draw and cleared the selection, and the editor never prevented it.

createKeyBindingMap

Since 3.9.2 the package exports createKeyBindingMap(), and the KeyBindingMap, KeyBindingName, and ShortcutOption types with it.
It returns the default key bindings, all 28 names with the fixed ones included, as a new map on every call, so changing the map it returns changes nothing else.
It is what every editor starts from, and a setKeyBindingMap call does not show in it.
Of these four only createKeyBindingMap is a runtime export; the other three are types. Since 4.2.0 dictionaryRowChords is exported beside it.

type KeyBindingName =
  | 'edit'
  | 'stop'
  | 'search'
  | 'findReplace'
  | 'undo'
  | 'redo'
  | 'addTable'
  | 'addColumn'
  | 'addMemo'
  | 'addTableGroup'
  | 'groupSelectedTables'
  | 'removeTable'
  | 'removeColumn'
  | 'removeSelection'
  | 'primaryKey'
  | 'selectAllTable'
  | 'selectAllColumn'
  | 'relationshipZeroOne'
  | 'relationshipZeroN'
  | 'relationshipOneOnly'
  | 'relationshipOneN'
  | 'tableProperties'
  | 'focusView'
  | 'zoomIn'
  | 'zoomOut'
  | 'zoomReset'
  | 'handTool'
  | 'zenMode';

type KeyBindingMap = Record<KeyBindingName, ShortcutOption[]>;

declare function createKeyBindingMap(): KeyBindingMap;

// example
import { createKeyBindingMap } from '@dineug/erd-editor';

const shortcuts = Object.values(createKeyBindingMap())
  .flat()
  .map(({ shortcut }) => shortcut); // 'Enter', 'Escape', '$mod+KeyK', ...

Each shortcut is a chord in tinykeys syntax that names its key by KeyboardEvent.code, where $mod is ⌘ on macOS and Control elsewhere.
Since 4.0.0 the editor reads these chords itself rather than through tinykeys, in the same syntax. A key matches by its code, or by its key in any letter case, and a press matches only with exactly the modifiers it names held. AltGraph counts as Control and Alt on Windows and as Alt on macOS. Presses separated by a space form a sequence, which starts over after a second without a keydown.
Since 4.1.0 one default is a sequence: groupSelectedTables is KeyT KeyG, T then G. A sequence runs on the press that completes it, and only that press takes its preventDefault and stopPropagation, so with the defaults T reaches the page and only G is prevented. Menus, quick search, and the Shortcuts tab show a sequence as one key per press.
The fixed names are bound to Enter (edit), Escape (stop), $mod+KeyZ (undo), $mod+Shift+KeyZ (redo), $mod+Equal (zoomIn), $mod+Minus (zoomOut), and $mod+Digit0 (zoomReset). edit and stop carry no flags; the other five carry preventDefault and stopPropagation. The rest are the defaults above, search and findReplace among them.

The editor listens for these on its own element, so a host that takes keys before the editor does, with global hotkeys or a capture-phase keydown listener, has to let them through while the editor is focused.
Build the list to let through from createKeyBindingMap(), with the bindings you passed to setKeyBindingMap in place of the defaults.
Since 3.10.0 that list includes $mod+KeyF, the browser's own find chord. A host that wants to keep its own find on that chord passes setKeyBindingMap({ findReplace: [] }).
Since 4.0.0 it also includes bare Delete and Backspace. A host that wants to keep those keys passes setKeyBindingMap({ removeSelection: [] }).
Since 4.1.0 it also includes Alt+KeyG and the sequence KeyT KeyG, which comes as one string: split it at the space and let each press through, bare T and G included, since a sequence missing a press never completes. A host that wants to keep those keys passes setKeyBindingMap({ addTableGroup: [] }) or setKeyBindingMap({ groupSelectedTables: [] }).
Since 4.2.0 add to it the chords dictionaryRowChords returns for the same map, Alt+Shift+Enter among them. A host that wants to keep those keys passes setKeyBindingMap({ addColumn: [] }) or setKeyBindingMap({ removeColumn: [] }), which also takes them off adding and removing columns on the ERD tab.

While the focus is inside the Explorer, in its tree, its Find and Replace fields, or its buttons, findReplace, search, undo, redo, zoomIn, zoomOut, and zoomReset pass through to the editor, so findReplace acts there as it does on the canvas. Every other binding, as currently set, stops at the Explorer, a sequence by its last press (a bare G with the defaults), and so do the arrow keys, Tab, Enter, Space, Home, End, and any key pressed while an IME is still composing. Apart from Escape, which gives the keyboard back to the canvas, they are stopped without being prevented, so they act as ordinary keys in the Explorer's fields, buttons, and tree and reach neither the canvas nor a page's bubbling keydown listener: Alt + N there adds no table, and Delete removes nothing. The keys that move, fold, or go to a tree row, and Enter in the Find or Replace field, which moves through the matches or replaces, are prevented as well.
Any other key, such as a host's save or command palette chord, goes on to the page as usual. See Keys in the Explorer. Before 4.1.0 the floating Find and Replace panel held keys the same way, apart from Home, End, the last press of a sequence, and Space while handTool was bound to another key.
Since 4.0.0 the Display Language picker holds keys the same way: the same seven bindings pass through, and every other binding (since 4.1.0 a sequence by its last press), the arrow keys, and Tab are stopped there without being prevented, as is any key pressed while an IME is still composing. ↑, ↓, Home, End, Enter, and Space on one of its rows move through the rows or pick one, and are prevented as well.

Since 4.2.0 the Dictionary tab holds keys too, with only search, findReplace, undo, and redo passing through to the editor. undo and redo run the shown sheet's own history, and with a cell edit open or the focus in the tab's search field they are left to the text, stopped there but not prevented. search and findReplace do nothing while a cell edit is open, as above. The row chords run in the grid, as described under addColumn and removeColumn above.
Every other binding, as currently set, stops at the tab, a sequence by its last press, and so do the arrow keys, Tab, Enter, Space, Home, End, and any key pressed while an IME is still composing. None of them reaches the canvas or a page's bubbling keydown listener: Alt + N there adds no table, and Delete removes nothing from the diagram. Copy, cut, and paste events in the tab stop there too, so the diagram never reads them as its own. Any other key goes on to the page as usual.

dictionaryRowChords

Since 4.2.0 the package exports dictionaryRowChords(). It returns, as a new ShortcutOption[] on every call, every chord with which the Dictionary tab's grid inserts or deletes rows under the key binding map you pass.
In order, they are the one-press chords of addColumn, which insert rows below the selection; each of those with Shift held as well, which insert rows above, none for a chord that already holds Shift; and the one-press chords of removeColumn, which delete rows. Each keeps the preventDefault and stopPropagation of the binding it comes from, and a sequence is left out. See Adding and Deleting Rows.
The chord that inserts rows above, Alt+Shift+Enter with the defaults, is in no binding, so a host that matches modifiers exactly and builds its list of keys to let through from createKeyBindingMap alone never lets it through. Let both lists through, as the Obsidian plugin does.
It reads only the map it is given, not the element's bindings, so pass it the map you built your list of keys from.

declare function dictionaryRowChords(
  keyBindingMap: KeyBindingMap
): ShortcutOption[];

// example
import { createKeyBindingMap, dictionaryRowChords } from '@dineug/erd-editor';

const map = createKeyBindingMap();
const shortcuts = [
  ...Object.values(map).flat(),
  ...dictionaryRowChords(map),
].map(({ shortcut }) => shortcut);
// dictionaryRowChords(map): 'Alt+Enter', 'Alt+Shift+Enter', 'Alt+Backspace', 'Alt+Delete'

$mod

Switches Control key depending on the environment.

• Mac: $mod = Meta (⌘)
• Windows/Linux: $mod = Control

Shortcut Table

Uses keyboard event key, code properties.
Use code for absolute positions and key for input values.

Windows	macOS	key	code
N/A	Command / ⌘	Meta	MetaLeft / MetaRight
Alt	Option / ⌥	Alt	AltLeft / AltRight
Control	Control / ^	Control	ControlLeft / ControlRight
Shift	Shift	Shift	ShiftLeft / ShiftRight
Space	Space	N/A	Space
Enter	Return	Enter	Enter
Esc	Esc	Escape	Escape
Backspace	Delete / ⌫	Backspace	Backspace
Delete	fn + Delete	Delete	Delete
1, 2, etc	1, 2, etc	1, 2, etc	Digit1, Digit2, etc
a, b, etc	a, b, etc	a, b, etc	KeyA, KeyB, etc
-	-	-	Minus
=	=	=	Equal
+	+	+	Equal

Theme

setPresetTheme

Sets a preset theme.
The defaults are appearance: 'dark', grayColor: 'slate', and accentColor: 'indigo'.
Each field is applied on its own, so a partial call leaves the other two as they are. A value that is not one of the names below is ignored, and the call never throws.
Since 4.0.0 appearance also takes 'system', the theme builder's System. It shows the light or dark the operating system reports, or the one setSystemAppearance names, and switches when that changes.

type ThemeOptions = {
  appearance: 'dark' | 'light' | 'system';
  grayColor: 'gray' | 'mauve' | 'slate' | 'sage' | 'olive' | 'sand';
  accentColor:
    | 'gray'
    | 'gold'
    | 'bronze'
    | 'brown'
    | 'yellow'
    | 'amber'
    | 'orange'
    | 'tomato'
    | 'red'
    | 'ruby'
    | 'crimson'
    | 'pink'
    | 'plum'
    | 'purple'
    | 'violet'
    | 'iris'
    | 'indigo'
    | 'blue'
    | 'cyan'
    | 'teal'
    | 'jade'
    | 'green'
    | 'grass'
    | 'lime'
    | 'mint'
    | 'sky';
};

// example
editor.setPresetTheme({ appearance: 'light' });

setSystemAppearance

Since 4.0.0, names the light or dark that the 'system' appearance shows, for a host with a light and dark of its own, such as an IDE theme. While one is named, the operating system's changes are ignored.
null, or any value other than 'dark' or 'light', goes back to following the operating system.
While the appearance is 'light' or 'dark' it changes nothing on screen, but the value is kept and applies as soon as the appearance becomes 'system'. Otherwise it applies at once. It emits nothing, and changePresetTheme keeps reporting 'system'.
The VS Code, JetBrains, and Obsidian hosts call it with their own light or dark, and again whenever that changes.

editor.setPresetTheme({ appearance: 'system' });
editor.setSystemAppearance('light'); // null follows the OS again

setTheme

Allows customizing the theme.
Every call replaces the whole custom overlay, so pass the full object again to change one token on top of an existing override, and pass {} to drop back to the preset.
Only the token names below, with string values, are kept; anything else is dropped without error.
The overlay sits on top of the preset, so a later setPresetTheme swaps the preset underneath while your overrides stay.

JavaScript

type Theme = {
  grayColor1: string;
  grayColor2: string;
  grayColor3: string;
  grayColor4: string;
  grayColor5: string;
  grayColor6: string;
  grayColor7: string;
  grayColor8: string;
  grayColor9: string;
  grayColor10: string;
  grayColor11: string;
  grayColor12: string;

  accentColor1: string;
  accentColor2: string;
  accentColor3: string;
  accentColor4: string;
  accentColor5: string;
  accentColor6: string;
  accentColor7: string;
  accentColor8: string;
  accentColor9: string;
  accentColor10: string;
  accentColor11: string;
  accentColor12: string;

  canvasBackground: string;
  canvasBoundaryBackground: string;

  tableBackground: string;
  tableHeaderBackground: string;
  tableSelect: string;
  tableBorder: string;
  tableShadow: string;

  tableGroupHeaderBackground: string;
  tableGroupBackground: string;
  tableGroupBorder: string;

  memoBackground: string;
  memoSelect: string;
  memoBorder: string;
  memoShadow: string;

  columnSelect: string;
  columnSelectHover: string;
  columnHover: string;

  columnHandleBackground: string;
  columnHandleBorder: string;
  columnHandleHoverBackground: string;
  columnHandleHoverBorder: string;

  relationshipHover: string;

  visualizationLink: string;
  visualizationColumn: string;
  visualizationRelationship: string;

  toolbarBackground: string;

  contextMenuBackground: string;
  contextMenuSelect: string;
  contextMenuHover: string;
  contextMenuBorder: string;

  minimapBorder: string;
  minimapShadow: string;
  minimapViewportBorder: string;
  minimapViewportBorderHover: string;

  toastBackground: string;
  toastBorder: string;
  toastSuccess: string;
  toastError: string;

  findReplaceError: string;

  mapColumnsError: string;

  schemaSqlWarningBackground: string;
  schemaSqlWarningForeground: string;

  dragSelectBackground: string;
  dragSelectBorder: string;

  scrollbarTrack: string;
  scrollbarThumb: string;
  scrollbarThumbHover: string;

  foreground: string;
  active: string;
  placeholder: string;

  focus: string;
  inputActive: string;

  keyPK: string;
  keyFK: string;
  keyPFK: string;

  treeBackground: string;
  treeRowHover: string;
  treeRowCurrent: string;
  treeMuted: string;
  treeMatch: string;

  explorerBackground: string;
  explorerBorder: string;

  dictionaryErrorForeground: string;
  dictionaryErrorBackground: string;
  dictionaryWarningForeground: string;
  dictionaryWarningBackground: string;
  dictionaryBackground: string;
  dictionaryHeaderBackground: string;
  dictionaryGridLine: string;
  dictionaryHeaderSelect: string;

  diffInsertForeground: string;
  diffDeleteForeground: string;
  diffModifyForeground: string;
  diffRenameForeground: string;
};

// example
editor.setTheme({
  canvasBackground: '#1b1b1f',
  tableBackground: '#242429',
  keyPK: '#ffc53d',
});

tableShadow and memoShadow are the color of the shadow tables and memos cast on the ERD canvas. The dark preset leaves them transparent, which casts none, as passing none or an empty string to setTheme does; the light preset uses rgba(0, 0, 0, 0.18).

Since 4.0.0 there are nine more tokens:

• tableGroupHeaderBackground, tableGroupBackground, and tableGroupBorder color the title bar, the body, and the outline of a table group that has no color of its own.
• toastSuccess and toastError color the mark of a toast that reports how something ended.
• findReplaceError and mapColumnsError color the errors Find and Replace and the Map Columns dialog show. Find and Replace used diffDeleteForeground before, so overriding that no longer recolors it.
• schemaSqlWarningBackground and schemaSqlWarningForeground color the warnings in the Schema SQL tab's options.

Since 4.1.0 there are nine more tokens:

• treeBackground, treeRowHover, treeRowCurrent, treeMuted, and treeMatch color the tree the Explorer and the Diff Viewer share: its background, which also fills the Explorer's Find and Replace fields; a row under the pointer, the keyboard's row while the tree has focus, and a button under the pointer in the Explorer's header and search; the row of the current search match; muted text such as counts, data types, and the folding arrows; and the mark behind the text a search found.
• explorerBackground and explorerBorder color the Explorer panel and its lines: its edge beside the canvas, the line under its search, and the borders of its fields and of the buttons Search In unfolds. explorerBorder also draws the Diff Viewer tree's edge, the line under its Filter by name field, and that field's border. The Explorer's key icons take keyPK, keyFK, and keyPFK.
• diffModifyForeground and diffRenameForeground color what the Diff Viewer marks changed and renamed, in its tree and on both documents. diffModifyForeground also outlines a table, memo, or table group that was moved, resized, recolored, or regrouped, whatever else changed in it, and draws the connector of a foreign key that changed.

diffInsertForeground and diffDeleteForeground now color what the Diff Viewer marks added and removed, in its tree and on the document that holds it, in text, outlines, and connectors alike. diffInsertBackground, diffDeleteBackground, diffCrossBackground, and diffCrossForeground were removed in 4.1.0, as the Diff Viewer no longer fills cells. setTheme drops them like any other name not in Theme, and their hooks, --erd-editor-diff-insert-background, --erd-editor-diff-delete-background, --erd-editor-diff-cross-background, and --erd-editor-diff-cross-foreground, are no longer read.

Since 4.2.0 there are twelve more tokens:

• columnHandleBackground and columnHandleBorder fill and outline the column drag handle, drawn just outside a table's left edge beside a focused column row, and columnHandleHoverBackground and columnHandleHoverBorder take over while the pointer is on it. Its grip takes foreground, and active under the pointer.
• dictionaryErrorForeground and dictionaryWarningForeground color what the dictionary checks find, an error or a warning: a flagged name on the ERD canvas (see Marks on the Canvas), the text of a flagged cell on the Domains, Words, and Terms sheets, and the Checks count. dictionaryErrorBackground and dictionaryWarningBackground fill such a cell. dictionaryErrorForeground also colors the Delete Rows tool under the pointer.
• dictionaryBackground, dictionaryHeaderBackground, dictionaryGridLine, and dictionaryHeaderSelect color the Dictionary tab's sheet: its cells, which also fill the tab's search field and a term's domain list; its column headers and row numbers; the lines between cells, which also draw the tab's bar and the borders of its fields; and a header whose row or column meets the selection. The rest of the sheet takes shared tokens: foreground for header labels, active for cell text, grayColor7 for the line that sets the column headers and the row numbers off from the cells, focus for the active cell's edge, accentColor9 for a selected range's edge and, at 20% opacity, its fill, accentColor6 for the header of a whole selected row or column, grayColor3 for read-only cells, and the scrollbar tokens. An accentColor9 not written as #rgb or #rrggbb leaves a selected range unfilled.

CSS Variables

Every token in Theme has a matching CSS hook named --erd-editor- plus the kebab-cased key: grayColor10 is --erd-editor-gray-color-10, keyPK is --erd-editor-key-pk, and keyPFK is --erd-editor-key-pfk.
The hooks are inherited into the editor, so set them wherever you want them to apply. On :root they theme every editor on the page; on the element itself they theme just that one.

erd-editor {
  --erd-editor-canvas-background: #1b1b1f;
}

Since 3.4.0 the misspelled dargSelect tokens are spelled dragSelect, and their hooks changed from --erd-editor-darg-select-background and --erd-editor-darg-select-border to --erd-editor-drag-select-background and --erd-editor-drag-select-border. A stylesheet still using the old names is ignored.

Default theme values

:root {
  --erd-editor-gray-color-1: #111113;
  --erd-editor-gray-color-2: #18191b;
  --erd-editor-gray-color-3: #212225;
  --erd-editor-gray-color-4: #272a2d;
  --erd-editor-gray-color-5: #2e3135;
  --erd-editor-gray-color-6: #363a3f;
  --erd-editor-gray-color-7: #43484e;
  --erd-editor-gray-color-8: #5a6169;
  --erd-editor-gray-color-9: #696e77;
  --erd-editor-gray-color-10: #777b84;
  --erd-editor-gray-color-11: #b0b4ba;
  --erd-editor-gray-color-12: #edeef0;
  --erd-editor-accent-color-1: #11131f;
  --erd-editor-accent-color-2: #141726;
  --erd-editor-accent-color-3: #182449;
  --erd-editor-accent-color-4: #1d2e62;
  --erd-editor-accent-color-5: #253974;
  --erd-editor-accent-color-6: #304384;
  --erd-editor-accent-color-7: #3a4f97;
  --erd-editor-accent-color-8: #435db1;
  --erd-editor-accent-color-9: #3e63dd;
  --erd-editor-accent-color-10: #5472e4;
  --erd-editor-accent-color-11: #9eb1ff;
  --erd-editor-accent-color-12: #d6e1ff;
  --erd-editor-canvas-background: #212225;
  --erd-editor-canvas-boundary-background: #111113;
  --erd-editor-table-background: #18191b;
  --erd-editor-table-header-background: #2e3135;
  --erd-editor-table-select: #435db1;
  --erd-editor-table-border: #363a3f;
  --erd-editor-table-shadow: transparent;
  --erd-editor-table-group-header-background: #43484e;
  --erd-editor-table-group-background: #d3edf81d;
  --erd-editor-table-group-border: #43484e;
  --erd-editor-memo-background: #18191b;
  --erd-editor-memo-select: #435db1;
  --erd-editor-memo-border: #363a3f;
  --erd-editor-memo-shadow: transparent;
  --erd-editor-column-select: #182449;
  --erd-editor-column-select-hover: #1d2e62;
  --erd-editor-column-hover: #272a2d;
  --erd-editor-column-handle-background: #18191b;
  --erd-editor-column-handle-border: #363a3f;
  --erd-editor-column-handle-hover-background: #2e3135;
  --erd-editor-column-handle-hover-border: #43484e;
  --erd-editor-relationship-hover: #435db1;
  --erd-editor-visualization-link: #43484e;
  --erd-editor-visualization-column: #5a6169;
  --erd-editor-visualization-relationship: #5a6169;
  --erd-editor-toolbar-background: #111113;
  --erd-editor-context-menu-background: #18191b;
  --erd-editor-context-menu-select: #272a2d;
  --erd-editor-context-menu-hover: #3a4f97;
  --erd-editor-context-menu-border: #363a3f;
  --erd-editor-minimap-border: black;
  --erd-editor-minimap-shadow: black;
  --erd-editor-minimap-viewport-border: #3a4f97;
  --erd-editor-minimap-viewport-border-hover: #435db1;
  --erd-editor-toast-background: #18191b;
  --erd-editor-toast-border: #363a3f;
  --erd-editor-toast-success: #3dd68c;
  --erd-editor-toast-error: #ff9592;
  --erd-editor-find-replace-error: #ff9592;
  --erd-editor-map-columns-error: #ff9592;
  --erd-editor-schema-sql-warning-background: #500f1c;
  --erd-editor-schema-sql-warning-foreground: #ff9592;
  --erd-editor-drag-select-background: #253974;
  --erd-editor-drag-select-border: #435db1;
  --erd-editor-scrollbar-track: #ddeaf814;
  --erd-editor-scrollbar-thumb: #696e77;
  --erd-editor-scrollbar-thumb-hover: #777b84;
  --erd-editor-foreground: #b0b4ba;
  --erd-editor-active: #edeef0;
  --erd-editor-placeholder: #e5edfd7b;
  --erd-editor-focus: #435db1;
  --erd-editor-input-active: #5472e4;
  --erd-editor-key-pk: #ffc53d;
  --erd-editor-key-fk: #e54666;
  --erd-editor-key-pfk: #00a2c7;
  --erd-editor-tree-background: #111113;
  --erd-editor-tree-row-hover: #212225;
  --erd-editor-tree-row-current: #1d2e62;
  --erd-editor-tree-muted: #b0b4ba;
  --erd-editor-tree-match: #253974;
  --erd-editor-explorer-background: #111113;
  --erd-editor-explorer-border: #363a3f;
  --erd-editor-dictionary-error-foreground: #ff9592;
  --erd-editor-dictionary-error-background: #500f1c;
  --erd-editor-dictionary-warning-foreground: #ffca16;
  --erd-editor-dictionary-warning-background: #3f2700;
  --erd-editor-dictionary-background: #18191b;
  --erd-editor-dictionary-header-background: #2e3135;
  --erd-editor-dictionary-grid-line: #363a3f;
  --erd-editor-dictionary-header-select: #182449;
  --erd-editor-diff-insert-foreground: #3dd68c;
  --erd-editor-diff-delete-foreground: #ff9592;
  --erd-editor-diff-modify-foreground: #ffca16;
  --erd-editor-diff-rename-foreground: #70b8ff;
}

Display Language

Since 4.0.0 the editor's own text — its menus, panels, dialogs, quick search, toasts, and the words it draws on the diagram such as unnamed, image exports included — comes in 25 languages. Table and column names, SQL, data types, and generated code are never translated. See Language and Theme.
Before setLocale is called or a language is picked, the editor shows English, or follows 'system' while enableLocalePicker is on.
The editor sets lang and dir on its own root inside the closed shadow root, never on the host element or the page, so a right-to-left page does not flip the editor and a right-to-left language does not flip the page. Hebrew, Arabic, and Persian lay the editor's interface out right to left; the diagram itself is never mirrored. Since 4.1.0 the Explorer stays at the left of the canvas in every language, its own rows reading right to left in those three.
The package exports the types LocaleCode (one of the codes below) and LocaleOption.

type LocaleOption = LocaleCode | 'system';

Code	Shown as	Language
id-ID	Bahasa Indonesia	Indonesian
de-DE	Deutsch	German
en	English	English
es-ES	Español	Spanish
eu-ES	Euskara	Basque
fr-FR	Français	French
it-IT	Italiano	Italian
nl-NL	Nederlands	Dutch
pl-PL	Polski	Polish
pt-PT	Português	Portuguese
pt-BR	Português Brasileiro	Brazilian Portuguese
ro-RO	Română	Romanian
sk-SK	Slovenčina	Slovak
sl-SI	Slovenščina	Slovenian
sv-SE	Svenska	Swedish
tr-TR	Türkçe	Turkish
ru-RU	Русский	Russian
uk-UA	Українська	Ukrainian
he-IL	עברית	Hebrew
ar-SA	العربية	Arabic
fa-IR	فارسی	Persian
ja-JP	日本語	Japanese
zh-CN	简体中文	Simplified Chinese
zh-TW	繁體中文	Traditional Chinese
ko-KR	한국어	Korean

setLocale

Sets the display language: 'system', or one of the codes above. Anything else, such as a bare 'ko', an unknown code, or a value that is not a string, is ignored without an error.
It applies before it returns, so a language set before the element is appended is in its first frame.
It emits nothing, neither changeLocale nor change, and touches none of value, the undo history, or a shared store.
The choice stays whichever way enableLocalePicker is turned, and setLocale('system') follows the system with the picker off too.
The editor stores nothing. To keep a reader's choice, listen for changeLocale and pass it back on the next load.

editor.enableLocalePicker = true;
editor.setLocale(localStorage.getItem('locale') ?? 'system');
editor.addEventListener('changeLocale', event => {
  localStorage.setItem('locale', event.detail.locale);
});

setSystemLocale

Names the language 'system' stands for, as a BCP 47 tag, for a host with a display language of its own. The VS Code, JetBrains, and Obsidian hosts call it with their own display language.
The tag is trimmed. null, a blank string, or a value that is not a string goes back to the browser's navigator.languages, which the editor follows as it changes.
It matters only while the option in force is 'system', and it applies at once. The picker's System row names the language it resolves to.
The tag, or each of the browser's languages in order, resolves to the first language the editor has, by its language subtag, with letter case and underscores ignored: de-AT gives de-DE and en-GB gives en. Chinese goes by its script, Hant giving zh-TW and Hans giving zh-CN, and without one by region, TW, HK, and MO giving zh-TW and any other zh-CN. pt gives pt-BR unless a region other than BR is named. When nothing matches, the editor shows English.

editor.setLocale('system');
editor.setSystemLocale('pt-PT'); // null follows the browser again

setSchemaSQL

Loads a Schema SQL file.
By default it replaces the current document rather than merging into it; see mode below. The settings you already have are kept, each lock and its locked value included, apart from the view position and the zoom level, and the tables are placed once the file is read, in rows unless placement below asks otherwise. With Viewport locked, value then writes the view the import starts on, origin 0, 0 at zoom level 1. A document imported into an element never given a value therefore has every lock on, as a new document does.
Since 4.2.0 a replace also keeps the document's words, terms, and domains, which the text cannot hold, with each Dictionary sheet's undo history, and an undo or redo of the import keeps them too. A replacing setSchemaJSON and assigning value take the ones their document holds instead.
It is recorded in the history list, enabling Undo, Redo, and it emits change. An empty string is ignored, and the call does nothing while readonly is set.
setSchemaGraphQL, setSchemaDBML, and setSchemaAML behave the same way, and their parsers never fail: text they cannot read loads an empty document rather than raising an error.
Since 4.0.0 all four take an optional second argument, { placement, mode }:

• placement: 'grid', the default, lands the tables in rows at once, as before, and the call returns nothing.
• placement: 'auto' first lays the tables out by their relationships, as Import in the editor does, and returns a Promise that resolves once the import has landed as one undo step. Fewer than two tables, no relationship, a layout that fails, a page without SharedWorker, or Cancel on the Placing tables toast lands them in rows instead. A load in the meantime — another replacing import, assigning value, setInitialValue(), since 5.1.0 a shared store's reseed, clear(), a collaborator's load, or an undo or redo of a load or of clear() — supersedes it, and the Promise resolves with nothing loaded. Imports placed this way land in the order they started.
• mode: 'replace', the default, replaces the document. mode: 'append' adds the file below the diagram as Import and Add does, leaving every table already there as it is, and every setting apart from the tab and the view position. From another tab the ERD tab comes up first. The new tables, and the table groups a DBML file brings while table groups are shown, become the selection, and the view scrolls to them unless they already show well, by the rule every jump follows since 4.1.0 — see Where a Jump Lands. One undo removes the whole addition. Text it cannot read adds nothing and leaves the document as it is.

While readonly is set, a replace is ignored, an append adds nothing, and a placement: 'auto' call resolves at once.
Since 3.10.0, setSchemaSQL reads the file for the document's current database: with Databricks selected, single-quoted strings follow Spark's backslash escapes. See Comments.
Since 3.10.0, setSchemaSQL reads a UNIQUE over two or more columns as one unique index rather than a Unique flag on each column. See Unique Keys and Indexes.
Since 3.10.0 SQL, DBML, and AML imports keep the ON DELETE and ON UPDATE actions of the foreign keys they read.
Since 4.0.0, setSchemaSQL keeps a column's whole DEFAULT expression, reads SQL Server's ADD DEFAULT … FOR and its MS_Description comments, turns PostgreSQL serial and identity columns into Auto Increment, keeps UNSIGNED and ZEROFILL in a data type, and reads a primary key that ALTER TABLE … ADD PRIMARY KEY marks CLUSTERED, NONCLUSTERED, or USING BTREE. See Schema SQL.
See Importing or Exporting Files for the syntax each parser accepts.

type SetSchema = {
  (
    value: string,
    options: { placement: 'auto'; mode?: 'replace' | 'append' }
  ): Promise<void>;
  (
    value: string,
    options?: { placement?: 'grid'; mode?: 'replace' | 'append' }
  ): void;
};

// example
editor.setSchemaSQL('Schema SQL...');
// or
await editor.setSchemaSQL('Schema SQL...', { placement: 'auto' });
// or
editor.setSchemaSQL('Schema SQL...', { mode: 'append' });

setSchemaGraphQL

Loads a GraphQL SDL document.
Object type definitions become tables, and a field whose type is another table becomes a relationship.

editor.setSchemaGraphQL('GraphQL SDL...');

setSchemaDBML

Loads a DBML file, the format used by dbdiagram.io and dbdocs.
Since 4.0.0 each TableGroup becomes a table group, and a table's headercolor becomes its color. See DBML.

editor.setSchemaDBML('DBML...');

setSchemaAML

Loads an AML (Azimutt Markup Language) file. Both the current spelling and the legacy v1 one are accepted.
Since 4.0.0 an entity's color, one of Azimutt's color names or a quoted hex value, becomes its table's color. See AML.

editor.setSchemaAML('AML...');

setSchemaJSON

Since 4.0.0, loads an .erd.json document, such as the text value returns.
In its default mode: 'replace' it loads the document as assigning value does: it is recorded in the history list, emits change, and takes the document's locks the same way, and since 4.2.0 the document's words, terms, and domains replace the editor's. Unlike value, an empty string or a value that is not a string is ignored rather than starting a new document. Text that is not JSON empties the document, as it does with value.
mode: 'append' adds the document's tables, relationships, indexes, memos, and table groups below the diagram under new ids, keeping their places relative to each other and leaving out the document's settings, as Import and Add does with a json file. Since 4.2.0 it keeps the tables' and columns' logical names and derived-name flags but leaves the document's words, terms, and domains behind, so none of its columns links a domain. Text it cannot read, or a document with no table and no memo, adds nothing. Otherwise it lands as a setSchemaSQL append does, its new memos and table groups selected with its tables, each kind while it is shown.
It returns once the document has landed, and it is ignored while readonly is set.

editor.setSchemaJSON('json...');
// or
editor.setSchemaJSON('json...', { mode: 'append' });

getSchemaSQL

Exports the current editor state as Schema SQL.
If databaseVendor is not specified, it writes for the database the editor shows: the document's, unless a read-only editor's reader picked another, which since 5.0.0 stays on that screen and is what its Schema SQL tab shows. A name that is not in the list below is treated the same way, without raising an error.
Names are quoted with the bracket type the editor shows. While Bracket Type is locked, or in a read-only editor whose reader picked another since 5.0.0, that can differ from the one value saves, which is the one a coding agent's erd_read quotes with. The names written are always the physical ones, whatever the Name View.
Since 4.0.0 an optional options argument chooses the statements and the header, as the options of the Schema SQL tab do, and since 4.2.0 whether logical names fill empty comments. SchemaSQLOptions is exported as a type.

• statements: 'create', the default; 'ifNotExists', which writes IF NOT EXISTS on MySQL, MariaDB, PostgreSQL, SQLite, and Databricks and falls back to 'create' elsewhere; or 'recreate', which drops the tables before creating them, Snowflake writing CREATE OR REPLACE TABLE instead.
• header: 'none', the default; 'use', which switches to the document's database or schema; or 'createAndUse', which first creates it if it does not exist and then switches to it. A database that lacks the one asked for falls back as the tab does: Oracle writes 'use' for 'createAndUse', PostgreSQL writes no header for 'use', and SQLite writes none. A header is written only while the document's database name is a plain identifier — ASCII letters, digits, and _, not starting with a digit.
• logicalNameAsComment, since 4.2.0: true writes a table's or column's logical name as its comment where its own comment is empty or only blanks and the logical name is not, in the form that database writes a comment. A comment with text is written as before. Only true turns it on: left out, false, or any other value, such as 'true' or 1, writes no logical name. It does what the tab's Write logical names into empty comments switch does.

An option left out, or one with an unknown value, reads as its default, so a call without options writes plain CREATE statements with no header, as before.
Since 4.0.0 the output always includes the document's Before tables and After tables scripts, in the order header, before script, drop statements, tables, after script. The Schema SQL tab's own Statements, Header, Write logical names into empty comments, and Tables choices never affect this call, which always writes the whole document.
Since 3.10.0 each foreign key carries the relationship's ON DELETE and ON UPDATE clauses. A clause is written only when its action is set and the vendor accepts it, so an action that vendor does not take is left out and its default applies. Since 4.0.0 Snowflake accepts only NO ACTION. See ON DELETE and ON UPDATE for what each database writes.
Since 3.10.0 a single quote inside a table or column comment is escaped, so a comment such as it's no longer breaks the statement. Every vendor that writes comments as string literals doubles it, except Databricks, which puts a backslash before each quote and each backslash. SQLite still writes comments as -- lines.
Since 4.2.0 SQL Server writes each comment as a national literal, N'…', so text outside the database's code page, such as Korean, is kept. Oracle writes each run of blank lines in a comment as one line break, and SQLite writes a comment's line breaks as spaces, so it stays on its -- line. See Comments.
Since 4.0.0 several databases also write key names, defaults, and auto increment differently. See What the DDL Writes.

type DatabaseVendor =
  | 'Databricks'
  | 'MariaDB'
  | 'MSSQL'
  | 'MySQL'
  | 'Oracle'
  | 'PostgreSQL'
  | 'Snowflake'
  | 'SQLite';

type SchemaSQLOptions = {
  statements?: 'create' | 'ifNotExists' | 'recreate';
  header?: 'none' | 'use' | 'createAndUse';
  logicalNameAsComment?: boolean;
};

const schemaSQL = editor.getSchemaSQL();
// or
const postgresSQL = editor.getSchemaSQL('PostgreSQL');
// or
const mysqlSQL = editor.getSchemaSQL('MySQL', {
  statements: 'ifNotExists',
  header: 'createAndUse',
});
// or
const commentedSQL = editor.getSchemaSQL('PostgreSQL', {
  logicalNameAsComment: true,
});

getSharedStore

Returns a store for real-time collaborative editing.
config is { getNickname?, mouseTracker?, focusTracker? }. Both trackers default to true: mouseTracker broadcasts this editor's cursor to the others, and focusTracker broadcasts its focused cell, selection, and drag box.
Since 5.0.0 the store sends no change while readonly is set, only what its trackers send and the registers a joining editor asks for, and it still applies what the others send.
Since 5.1.0 it also hands out the editor's collaboration registers and its clock's version (getLWW, getVersion), takes another store's in (mergeLWW), forgets a departed collaborator's cursor, focus, selection, and drag box (forgetPeer), and reopens the session's document with the registers held beside it (reseed). @dineug/erd-editor-yjs relies on these to keep the element in step with a Yjs document.
Since 5.1.0 two users who change one name or field, move one table, or move or resize one memo or table group at the same moment end alike on every editor and replica of 5.1.0 or later, and a drag, a pan, or a zoom is sent as where it ends.
A color, a column moved within its table or index, and a few settings such as the database are the exceptions, which each editor and replica still takes in the order it hears them. See Concurrent Edits.
See Collaborative Editing.

const sharedStore = editor.getSharedStore({
  mouseTracker: false,
  focusTracker: false,
});

setDiffValue

Opens the Diff Viewer, comparing the document currently open against the one you pass.
It returns nothing and does not modify the document, so closing the viewer leaves the editor exactly as it was.
A blank value, or anything that is not a string, is compared against an empty document.
It is the same overlay as Diff Viewer in the canvas context menu.
Since 4.1.0 it pairs what the two documents hold by id first and only then by what each keeps, such as a table's name or a memo's text — see What Is Compared. Against an earlier version of the same document, such as a Git revision of its file, a rename therefore shows as one renamed item; against a document whose ids differ, it shows as a removal and an addition. The viewer lists what changed in a tree beside the two documents and marks the changes in color instead of filling cells.
Since 4.2.0 both documents open in the Name View this editor shows, whatever the document passed saved, and the tree names tables and columns by it too — see Beyond the Canvas. Logical names, domain links, and the dictionaries are not compared, so a change to them alone shows no change.

editor.setDiffValue('prev json...');
